Quick Details

  • Light Source: LED
  • Input Voltage(V): AC100-264/47-63Hz
  • Lamp Power(W): 120
  • Working Lifetime(Hour): 100000
  • IP Rating: IP20
  • Certification: CE, RoHS
  • Brand Name: DAISEYA
  • Model Number: ML-Q4006-MATRIX
  • Emitting Color: RGBW 4in1
  • beam angle: 4.5 degree
  • color effect: RGBW 4-IN-1 mixing
  • Warranty: 1 Year
  • Control mode: 24/32/40/19/17



Light source and optics
6 x 40W RGBW FullColor LEDs
Beam angle: 4,5
67mm high definition narrow lens
Driving current: 2,5A
Lux @3m: 39676lux at 4,5 CCT:18361
Color synthesis: RGBW FullColor mixing (>16 million colors) for a limitless color range and variable CTC
control
White temperature presets: 3200K~10000K
Electronic linear pivot with motorized and scrolling lens panel
Pivot angle: -3 to +12
Pivot speed (from 0 to 100%): 3.5sec
LEDs average life span: >50 000 h
Dimmer/Shutter/Strobe/Colors/Pixels
0-100% linear,16-bit dimmer
Independent shutter and fading effects with adjust able speed and random strobe
Strobe: Electronic, 1-20 flash per second
Virtual color wheel with LEE and rainbow presets
DMX channel mode:STAND,EXTEND,PIXEL,IHSC,CMY,HALO, etc.
CTC control through independent DMX channel
Several dynamic and static pre-built pixel Macros with adjustable Speed, Dimmer, foreground and
background colors
Electronics
LCD display with high resolution for simplified access to control menu, configuration and DMX
addressing
Menu language: English
DMX configurations available: 24/32/40/19/19/17 channels for full flexibility and control (preliminary)
Input and output signal through 3p XLR
DMX ready to set DMX Address, personal mode.
Via ID code, overall or individual control flexibly
Remote unit reset by DMX
Fixture life timer:>=50000 hours
Temperature protect function,with thermal and fan rotation control.
Dynamic screen saver,three Backlight modes: short,long,always.
Built in menu protection
Structure and moving body
Internal protection: IP20
Cooling: forced ventilation with low-noise fans, no heat generation
Ergonomic handles for easy transport
Continuous rotation on Pan and Tilt axes
Max number laps for infinity pan and tilt: 10.000.000
Motion Angle: Pan = 630 (1.8 sec), Tilt = 360 (0,5 sec)
Pan/Tilt resolution: Pan/Tilt fine = 0.01875
Power supply
Power supply: 100-240V 50/60Hz
Connections: PowerCON TRUE IN
Max power consumption: 300W
Weight and dimensions
Weight: 15.5 kg
Dimensions (WxHxD): 591x349x236mm
